Ashcroft® pressure gauges have earned a reputation
for dependability as a mainstay in the marketplace for over 150
years. Ashcroft® industrial pressure gauges are offered in a wide
assortment of dial sizes, case styles and wetted parts materials.
Ashcroft® Pressure Gauge Selection
pressure gauges are available in a variety of sizes and materials to
meet the demands of the industrial marketplace. When selecting an
Ashcroft® pressure gauge, consider these seven steps:
Media — Ashcroft® pressure gauges are available in a wide
selection of Bourdon tube and socket materials to fit your
Pressure Gauge Range — available with ranges as low as 10 inches
of water through 100,000 psi, Ashcroft® pressure gauges have been
designed to meet your application needs.
Operating Environment — available in case materials of stainless
steel, black epoxy-coated aluminum and phenolic, these gauges have
been designed to withstand the most demanding environments. Most
Ashcroft® gauges are available with an optional built-in throttle
plug to help protect against pressure surges or spikes.
Accuracy Requirements — all general service type Ashcroft®
industrial gauges are offered with a 1% ASME Grade 1A accuracy. For
a higher degree of accuracy, Ashcroft® process gauges are offered
with a 0.5% ASME Grade 2A accuracy.
Size — available with dial sizes from 21⁄2 through 81⁄2 inches,
Ashcroft® gauges come in sizes to meet your space requirements with
optimum gauge readability.
Connections — availability includes, but is not limited to 1⁄4
NPT, 1⁄2 NPT, BSP, JIS and SAE connections.
Mounting Requirements — depending on the type, Ashcroft® gauges
are available for stem, surface or flush mounting.
To start, please select a basic
type of Ashcroft® gauge
or contact us for help:
